Electric concrete pump is a kind of concrete pump adopting electrical engine power source, it mainly used for concrete transportation. It adopts electricity as its original power, unlike the diesel concrete pump, the concrete pump with electric engine only can work in the areas with sufficient electricity power. The electric concrete pump adopts the electric motor, which can provide stead and constant power when it is on work. Compared with the diesel engine concrete pump, the concrete pumps with electric motor is more convenient and used widely.Application industry: Concrete / Cement Products (Blocks, Pavers, Curbstones, Sleepers, Pipes, Rings), Precast Elements (Beams, Hollow Core, Safety Barriers, Wall Panels) ,Dam Construction, Road Paving, Industrial Floors, Architectural Precast, Waste Treatment, Foundries, Glass Industry, Mine Industry (muds treatment, backfilling),Soil Stabilization, Fertilizers.

Hot Sale in stock: DHBT60 Diesel concrete pump - HBT40 Electric concrete pump - HBT15 Concrete mixing pump - 37m Concrete Boom Pump Truck - 21m Concrete Placing Boom - HBT60 Electric concrete pump

Benefits & Features

1. Radiator: adopts the air-cooled plate-fin radiator to ensure that the system could operate in a maximum temperature allowed.
2. The main oil pump: adopts the German Hawe / Rexroth / Japanese Kawasaki series.
3. Lubrication system: adopts the automatic multi-point lubrication technology featuring one to one lubrication with better efficiency and the extending service life of wearing parts.
4. Power system: the power of motor series uses the well-known domestic and foreign brands: Yantai motor, Qingdao motor, Siemens Beide motor.
5. Diesel Series: power system employs the Lovol or Deutz diesel engine;
6. Electrical parts: the main electrical products adopts Schneider , LG products to the reliability of the electronic control system.
7. Hydraulic Hose Fittings: adopts the US Eaton products to ensure the safety of the hydraulic system, no leakage.
8. Large cylinder seals: Large cylinder seals adopts the US Parker products.
9. S valve: employing the manganese steel overall casting, the wearing surface adopts wear-resistant materials featuring the dual advantages of pressure and abrasion resistant.
10. Glasses plate cutting ring: glasses plates and cutting ring inlaid adopts the carbide hard to ensure a durable design.
11. Pistons: adopts the imported materials and precision machining, with excellent qualities: hydrolysis resistance, wear resistance and high temperature resistance.

Tags: concrete pump truck in Davao portable concrete pump for sale in Iloilo Electromotor concrete pumps in Mandawi self concrete mixer in Iloilo simple brick making machine in Sanbaoyan 4m3 Concrete Mixing Truck in baguio ajax self loader in Illigan

More Info

Item		Unit	S Valve Concrete Pump
			HBT30	HBT40	HBT50	HBT60			HBT80
Theoretic Concrete Delivery Volume	Low Pressure	M3/H	30	40	50	60			80
	High Pressure	M3/H	/	/	23	36			48
Concrete Delivery Pressure	Low Pressure	MPa	/	/	5.8	6.3			8.3
	High Pressure	MPa	10	10	12	13			16
Hydraulic Pressure		MPa	25	28	28	28			28
Electric Motor Speed		R/Min	1480
Main hydraulic Pump			JINDA	Kawasaki
Main Cylinder Dia./Pole Dia.× Stroke		mm	Φ80/55×845	Φ100/70×1100	Φ110/70×1300	Φ120/80×1650			Φ140/90×1800
Diameter Of Delivery Cylinder		mm	140	160/180	180	200	200
Electric Motor Power		KW	37	45	55	90	110
Capacity Of Hydraulic Oil Tank		L	200	370	370	560	560
Hopper Capacity		M3	0.4		0.55	0.6
Overall Weight		Kg	2300	3500	3600	5000		5600
Max. Delivery Distance	Vertical	M	100	160	160	160		160
	Horizontal	M	300	500	500	800		1000
